| Customization: | Available |
|---|---|
| Type: | Li-ion Battery |
| Warranty: | 1 Year |
| Quantity: | |
|---|---|
| Nominal Voltage | 3.2V |
| Nominal Capacity | 1500mAh |
| Typical Capacity | 1530mAh after standard charge and standard discharge |
| Standard Charge | Constant current at 750mA charge to 3.65V, then constant voltage at 3.65V charge till current decline to ≤15mA |
| Fast Charge | Constant current at 1500mA charge to 3.65V, then constant voltage at 3.65V charge till current decline to ≤15mA |
| Standard Discharge | 300mA to 2.0V |
| Fast Discharge | 1500mA to 2.0V |
| Maximum Continuous Charge Current | 1500mA |
| Maximum Continuous Discharge Current | 4500mA |
| Operating Temperature | Charge 0°C to 45°C Discharge -20°C to 60°C |
| Dimensions | Diameter 18.7mm Height 65.5mm |
| Typical Weight | 42g |
