| Customization: | Available |
|---|---|
| Type: | Li-ion Battery |
| Cathode Material: | Ncm/Lco |
| Quantity: | |
|---|---|
| Model Name | ICR14500-800 |
| Nominal Voltage | 3.2V |
| Nominal Capacity | 800mAh |
| Typical Capacity | 830mAh after standard charge and standard discharge |
| Minimum Capacity | 780mAh after standard charge and standard discharge |
| Standard Charge | Constant current at 400mA charge to 4.20V, then constant voltage at 4.20V charge till current decline to ≤8mA |
| Fast Charge | Constant current at 800mAcharge to 4.20V, then constant voltage at 4.20Vcharge till current decline to ≤8mA |
| Standard Discharge | 160mA to 2.75V |
| Fast Discharge | 800mA to 2.75V |
| Maximum Continuous Charge Current | 160mA(0ºCto 10ºC) 400mA(10ºCto 20ºC) 800mA(20ºCto 45ºC) |
| Maximum Continuous Discharge Current | 1600mA |
| Operating Temperature | Charge 0ºC to 45ºC Discharge -20ºC to 60ºC |
| Storage Temperature | <1 year -20ºC to 25ºC <3 months -20ºC to 40ºC <30days -20ºC to 50ºC |
| Typical Weight | 19g |
