| Customization: | Available |
|---|---|
| Type: | Li-ion Battery |
| Cathode Material: | LFP |
| Quantity: | |
|---|---|
| Model Name | LFP22650-2000 |
| Nominal Voltage | 3.2V |
| Nominal Capacity | 2000mAh |
| Typical Capacity | 2080mAh after standard charge and standard discharge |
| Minimum Capacity | 1950mAh after standard charge and standard discharge |
| Standard Charge | Constant current at1000mAcharge to 3.65V, then constant voltage at 3.65Vcharge till current decline to ≤20mA |
| Fast Charge | Constant current at2000mAcharge to 3.65V, then constant voltage at 3.65Vcharge till current decline to ≤20mA |
| Standard Discharge | 400mA to 2.0V |
| Fast Discharge | 2000mA to 2.0V |
| Maximum Continuous Charge Current | 400mA(0ºCto 10ºC) 1000mA(10ºCto 20ºC) 2000mA(20ºCto 60ºC) |
| Maximum Continuous Discharge Current | 6000mA |
| Operating Temperature | Charge 0ºC to 60ºC Discharge -20ºC to 60ºC |
| Storage Temperature | <1 year -20ºC to 25ºC <3 months -20ºC to 40ºC <30days -20ºC to 50ºC |
| Typical Weight | 62g |
