LFP14430-400
JYH
The LFP14430-400 is a premium lithium iron phosphate battery delivering 400mAh nominal capacity (420mAh typical) in a compact 14430 form factor. Designed for space-constrained safety applications, it combines LiFePO4's inherent safety with reliable performance for medical and emergency devices.
| Model | LFP14430-400 |
| IEC Designation | IFpR15/44 |
| Nominal Voltage | 3.2V |
| Nominal Capacity | 400mAh |
| Typical Capacity | 420mAh after standard charge and standard discharge |
| Minimum Capacity | 380mAh after standard charge and standard discharge |
| Standard Charge | Constant current at 200mA charge to 3.65V, then constant voltage at 3.65V charge till current decline to ≤4mA |
| Fast Charge | Constant current at 400mA charge to 3.65V, then constant voltage at 3.65V charge till current decline to ≤4mA |
| Standard Discharge | 80mA to 2.0V |
| Fast Discharge | 400mA to 2.0V |
| Maximum Continuous Charge Current | 400mA |
| Maximum Continuous Discharge Current | 1200mA |
| Operating Temperature | Charge 0℃ to 45℃ Discharge -20℃ to 60℃ |
| Storage Temperature | <1 year -20℃ to 25℃ <3 months -20℃ to 40℃ <30days -20℃ to 50℃ |
| Typical Weight | 16g |
