ICR14430-650
JYH
The ICR14430-650 is a high-performance lithium-ion battery delivering 650mAh nominal capacity (680mAh typical) in a compact 14430 form factor. Designed specifically for personal care devices, it combines optimized power delivery with safety-certified reliability for daily-use electronics.
| Model | ICR14430-650 |
| Nominal Voltage | 3.7V |
| Nominal Capacity | 650mAh |
| Typical Capacity | 680mAh after standard charge and standard discharge |
| Minimum Capacity | 630mAh after standard charge and standard discharge |
| Standard Charge | Constant current at 325mA charge to 4.2V, then constant voltage at 4.2V charge till current decline to ≤6.5mA |
| Fast Charge | Constant current at 650mA charge to 4.2V, then constant voltage at 4.2V charge till current decline to ≤6.5mA |
| Standard Discharge | 130mA to 2.75V |
| Fast Discharge | 650mA to 2.75V |
| Maximum Continuous Charge Current | 650mA |
| Maximum Continuous Discharge Current | 1300mA |
| Operating Temperature | Charge 0℃ to 45℃ Discharge -20℃ to 60℃ |
| Storage Temperature | <1 year -20℃ to 25℃ <3 months -20℃ to 40℃ <30days -20℃ to 50℃ |
| Typical Weight | 16g |
