ICR14500-850
JYH
The ICR14500-850 sets a new standard for AA-size lithium-ion batteries, delivering an industry-leading 850mAh nominal capacity (880mAh typical). Engineered for the most demanding professional applications, this battery combines breakthrough energy density with military-grade reliability in a standard AA form factor.
| Model | ICR14500-850 |
| Nominal Voltage | 3.7V |
| Nominal Capacity | 850mAh |
| Typical Capacity | 880mAh after standard charge and standard discharge |
| Minimum Capacity | 820mAh after standard charge and standard discharge |
| Standard Charge | Constant current at 425mA charge to 4.2V, then constant voltage at 4.2V charge till current decline to ≤8.5mA |
| Fast Charge | Constant current at 850mA charge to 4.2V, then constant voltage at 4.2V charge till current decline to ≤8.5mA |
| Standard Discharge | 170mA to 2.75V |
| Fast Discharge | 850mA to 2.75V |
| Maximum Continuous Charge Current | 850mA |
| Maximum Continuous Discharge Current | 1700mA |
| Operating Temperature | Charge 0℃ to 45℃ Discharge -20℃ to 60℃ |
| Storage Temperature | <1 year -20℃ to 25℃ <3 months -20℃ to 40℃ <30days -20℃ to 50℃ |
| Typical Weight | 19g |
